Description
Specifications:
| Item | PF20 |
| Certificate | CE, CCC, RoHS, SGS |
| Rated Voltage(V) | 100-127/220-240 |
| Rated Frequency(Hz) | 50/60 |
| Rated Output Power(W) | 900 |
| Rotation | CW |
| Max Vacuum Degree(Kpa) | 18 |
| Max Air Flow(M3/min) | 2.5 |
| Max Suction Power (W) | 260 |
| Max Suction Efficiency(%) | 36 |
| Motor Speed(Rpm) | 28000 |
| Spark Grade | ≤2 |
| Vibration(mm/s) | ≤15 |
| Noise(dB) | ≤98 |
| Insulation Level | E |
| Life | ≥500h |
| Size(mm) | Top 122, bottom 130, height 118 |
Size Drawing:
